/* status error */
|
|
|
|
DCAMERR_BUSY
|
0x80000101
|
API cannot process in busy state.
|
|
DCAMERR_NOTREADY
|
0x80000103
|
API requires ready state.
|
|
DCAMERR_NOTSTABLE
|
0x80000104
|
API requires stable or unstable state.
|
|
DCAMERR_UNSTABLE
|
0x80000105
|
API does not support in unstable state.
|
|
DCAMERR_NOTBUSY
|
0x80000107
|
API requires busy state.
|
|
|
|
|
|
DCAMERR_EXCLUDED
|
0x80000110
|
some resource is exclusive and already used
|
|
|
|
|
|
DCAMERR_COOLINGTROUBLE
|
0x80000302
|
something happens near cooler
|
|
DCAMERR_NOTRIGGER
|
0x80000303
|
no trigger when necessary. Some camera supports this error.
|
|
DCAMERR_TEMPERATURE_TROUBLE
|
0x80000304
|
camera warns its temperature
|
|
DCAMERR_TOOFREQUENTTRIGGER
|
0x80000305
|
input too frequent trigger. Some camera supports this error.
|
|
|
|
|
|
/* wait error */
|
|
|
|
DCAMERR_ABORT
|
0x80000102
|
abort process
|
|
DCAMERR_TIMEOUT
|
0x80000106
|
timeout
|
|
DCAMERR_LOSTFRAME
|
0x80000301
|
frame data is lost
|
|
DCAMERR_MISSINGFRAME_TROUBLE
|
0x80000f06
|
frame is lost but reason is low lever driver's bug
|
|
DCAMERR_INVALIDIMAGE
|
0x80000321
|
hpk format data is invalid data
|
|
|
|
|
|
/* initialization error */
|
|
|
|
DCAMERR_NORESOURCE
|
0x80000201
|
not enough resource except memory
|
|
DCAMERR_NOMEMORY
|
0x80000203
|
not enough memory
|
|
DCAMERR_NOMODULE
|
0x80000204
|
no sub module
|
|
DCAMERR_NODRIVER
|
0x80000205
|
no driver
|
|
DCAMERR_NOCAMERA
|
0x80000206
|
no camera
|
|
DCAMERR_NOGRABBER
|
0x80000207
|
no grabber
|
|
DCAMERR_NOCOMBINATION
|
0x80000208
|
no combination on registry
|
|
|
|
|
|
DCAMERR_FAILOPEN
|
0x80001001
|
DEPRECATED
|
|
DCAMERR_INVALIDMODULE
|
0x80000211
|
dcam_init() found invalid module
|
|
DCAMERR_INVALIDCOMMPORT
|
0x80000212
|
invalid serial port
|
|
DCAMERR_FAILOPENBUS
|
0x81001001
|
the bus or driver are not available
|
|
DCAMERR_FAILOPENCAMERA
|
0x82001001
|
camera report error during opening
|
|
DCAMERR_FRAMEGRABBER_NEEDS_FIRMWAREUPDATE
|
0x80001002
|
need to update frame grabber firmware to use the camera
|
|
|
|
|
|
/* calling error */
|
|
|
|
DCAMERR_INVALIDCAMERA
|
0x80000806
|
invalid camera
|
|
DCAMERR_INVALIDHANDLE
|
0x80000807
|
invalid camera handle
|
|
DCAMERR_INVALIDPARAM
|
0x80000808
|
invalid parameter
|
|
DCAMERR_INVALIDVALUE
|
0x80000821
|
invalid property value
|
|
DCAMERR_OUTOFRANGE
|
0x80000822
|
value is out of range
|
|
DCAMERR_NOTWRITABLE
|
0x80000823
|
the property is not writable
|
|
DCAMERR_NOTREADABLE
|
0x80000824
|
the property is not readable
|
|
DCAMERR_INVALIDPROPERTYID
|
0x80000825
|
the property id is invalid
|
|
DCAMERR_NEWAPIREQUIRED
|
0x80000826
|
old API cannot present the value because only new API need to be used
|
|
DCAMERR_WRONGHANDSHAKE
|
0x80000827
|
this error happens DCAM get error code from camera unexpectedly
|
|
DCAMERR_NOPROPERTY
|
0x80000828
|
there is no alternative or influence id, or no more property id
|
|
DCAMERR_INVALIDCHANNEL
|
0x80000829
|
the property id specifies channel but channel is invalid
|
|
DCAMERR_INVALIDVIEW
|
0x8000082a
|
the property id specifies channel but channel is invalid
|
|
DCAMERR_INVALIDSUBARRAY
|
0x8000082b
|
the combination of subarray values are invalid. e.g. DCAM_IDPROP_SUBARRAYHPOS + DCAM_IDPROP_SUBARRAYHSIZE is greater than the number of horizontal pixel of sensor.
|
|
DCAMERR_ACCESSDENY
|
0x8000082c
|
the property cannot access during this DCAM STATUS
|
|
DCAMERR_NOVALUETEXT
|
0x8000082d
|
the property does not have value text
|
|
DCAMERR_WRONGPROPERTYVALUE
|
0x8000082e
|
at least one property value is wrong
|
|
DCAMERR_DISHARMONY
|
0x80000830
|
the paired camera does not have same parameter
|
|
DCAMERR_FRAMEBUNDLESHOULDBEOFF
|
0x80000832
|
frame bundle mode should be OFF under current property settings
|
|
DCAMERR_INVALIDFRAMEINDEX
|
0x80000833
|
the frame index is invalid
|
|
DCAMERR_INVALIDSESSIONINDEX
|
0x80000834
|
the session index is invalid
|
|
DCAMERR_NOCORRECTIONDATA
|
0x80000838
|
not take the dark and shading correction data yet.
|
|
DCAMERR_CHANNELDEPENDENTVALUE
|
0x80000839
|
each channel has own property value so can't return overall property value.
|
|
DCAMERR_VIEWDEPENDENTVALUE
|
0x8000083a
|
each view has own property value so can't return overall property value.
|
|
DCAMERR_INVALIDCALIBSETTING
|
0x8000083e
|
the setting of properties are invalid on sampling calibration data. some camera has the limitation to make calibration data. e.g. the trigger source is INTERNAL only and read out direction isn't trigger.
|
|
DCAMERR_LESSSYSTEMMEMORY
|
0x8000083f
|
the system memory size is too small. PC doesn't have enough memory or is limited memory by 32bit OS.
|
|
DCAMERR_NOTSUPPORT
|
0x80000f03
|
camera does not support the function or property with current settings
|
|
|
|
|
|
/* camera or bus trouble */
|
|
|
|
DCAMERR_FAILREADCAMERA
|
0x83001002
|
failed to read data from camera
|
|
DCAMERR_FAILWRITECAMERA
|
0x83001003
|
failed to write data to the camera
|
|
DCAMERR_CONFLICTCOMMPORT
|
0x83001004
|
conflict the com port name user set
|
|
DCAMERR_OPTICS_UNPLUGGED
|
0x83001005
|
Optics part is unplugged so please check it.
|
|
DCAMERR_FAILCALIBRATION
|
0x83001006
|
fail calibration
|
|
|
|
|
|
/* 0x84000100 - 0x840001FF, DCAMERR_INVALIDMEMBER_x */
|
|
|
|
DCAMERR_INVALIDMEMBER_3
|
0x84000103
|
3th member variable is invalid value
|
|
DCAMERR_INVALIDMEMBER_5
|
0x84000105
|
5th member variable is invalid value
|
|
DCAMERR_INVALIDMEMBER_7
|
0x84000107
|
7th member variable is invalid value
|
|
DCAMERR_INVALIDMEMBER_8
|
0x84000108
|
8th member variable is invalid value
|
|
DCAMERR_INVALIDMEMBER_9
|
0x84000109
|
9th member variable is invalid value
|
|
DCAMERR_FAILEDOPENRECFILE
|
0x84001001
|
DCAMREC failed to open the file
|
|
DCAMERR_INVALIDRECHANDLE
|
0x84001002
|
DCAMREC is invalid handle
|
|
DCAMERR_FAILEDWRITEDATA
|
0x84001003
|
DCAMREC failed to write the data
|
|
DCAMERR_FAILEDREADDATA
|
0x84001004
|
DCAMREC failed to read the data
|
|
DCAMERR_NOWRECORDING
|
0x84001005
|
DCAMREC is recording data now
|
|
DCAMERR_WRITEFULL
|
0x84001006
|
DCAMREC writes full frame of the session
|
|
DCAMERR_ALREADYOCCUPIED
|
0x84001007
|
DCAMREC handle is already occupied by other HDCAM
|
|
DCAMERR_TOOLARGEUSERDATASIZE
|
0x84001008
|
DCAMREC is set the large value to user data size
|
|
DCAMERR_NOIMAGE
|
0x84001804
|
not stored image in buffer on bufrecord
|
|
DCAMERR_INVALIDWAITHANDLE
|
0x84002001
|
DCAMWAIT is invalid handle
|
|
DCAMERR_NEWRUNTIMEREQUIRED
|
0x84002002
|
DCAM Module Version is older than the version that the camera requests
|
|
DCAMERR_VERSIONMISMATCH
|
0x84002003
|
Camera returns the error on setting parameter to limit version
|
|
DCAMERR_RUNAS_FACTORYMODE
|
0x84002004
|
Camera is running as a factory mode
|
|
DCAMERR_IMAGE_UNKNOWNSIGNATURE
|
0x84003001
|
signature of image header is unknown or corrupted
|
|
DCAMERR_IMAGE_NEWRUNTIMEREQUIRED
|
0x84003002
|
version of image header is newer than version that used DCAM supports
|
|
DCAMERR_IMAGE_ERRORSTATUSEXIST
|
0x84003003
|
image header stands error status
|
|
DCAMERR_IMAGE_HEADERCORRUPTED
|
0x84003004
|
image header value is strange
|
|
DCAMERR_IMAGE_BROKENCONTENT
|
0x84003005
|
image content is corrupted
|
|
|
|
|
|
/* calling error for DCAM-API 2.1.3 */
|
|
|
|
DCAMERR_UNKNOWNMSGID
|
0x80000801
|
unknown message id
|
|
DCAMERR_UNKNOWNSTRID
|
0x80000802
|
unknown string id
|
|
DCAMERR_UNKNOWNPARAMID
|
0x80000803
|
unknown parameter id
|
|
DCAMERR_UNKNOWNBITSTYPE
|
0x80000804
|
unknown bitmap bits type
|
|
DCAMERR_UNKNOWNDATATYPE
|
0x80000805
|
unknown frame data type
|
|
|
|
|
|
/* internal error */
|
|
|
|
DCAMERR_NONE
|
0
|
no error, nothing to have done
|
|
DCAMERR_INSTALLATIONINPROGRESS
|
0x80000f00
|
installation progress
|
|
DCAMERR_UNREACH
|
0x80000f01
|
internal error
|
|
DCAMERR_UNLOADED
|
0x80000f04
|
calling after process terminated
|
|
DCAMERR_THRUADAPTER
|
0x80000f05
|
|
|
DCAMERR_NOCONNECTION
|
0x80000f07
|
HDCAM lost connection to camera
|
|
|
|
|
|
DCAMERR_NOTIMPLEMENT
|
0x80000f02
|
not yet implementation
|
|
|
|
|
|
DCAMERR_APIINIT_INITOPTIONBYTES
|
0x80000f03
|
DCAMAPI_INIT::initoptionbytes is invalid
|
|
DCAMERR_APIINIT_INITOPTION
|
0x80000f04
|
DCAMAPI_INIT::initoption is invalid
|
|
|
|
|
|
DCAMERR_INITOPTION_COLLISION_BASE
|
0xa401C000,
|
|
|
DCAMERR_INITOPTION_COLLISION_MAX
|
0xa401FFFF,
|
|
|
|
|
|
|
/* success */
|
|
|
|
DCAMERR_SUCCESS
|
1
|
no error, general success code, app should check the value is positive
|
